Acid-resisting Asbestos Rubber Sheet
Code : WB-AF3915
Short Description:
Specification: Description: It s made of good asbestos fiber with acid-resisting synthetic rubber compression heating and compression molding it. APPLICATION: Mainly used for the equipment in acid, and used as sealing materials of gaskets for the flange of pipeline joints. PARAMETER: Item Style 3915A 3915B 3915C Horizontal Strain ≥MPa 14 11 8 Weight-increasing 96.17%( H2SO4) =18mol/L*48h ≤30% ≤30% ≤30% 36.97%(HCL)=12mol/L*48h ≤25% ≤25% ≤25% 10% (HNO3)= 1.6...
Product Detail
Product Tags
Specification:
Description: It s made of good asbestos fiber with acid-resisting synthetic rubber compression heating and compression molding it.
APPLICATION:
Mainly used for the equipment in acid, and used as sealing materials of gaskets for the flange of pipeline joints.
PARAMETER:
| Item |
Style |
3915A |
3915B |
3915C |
|
| Horizontal Strain ≥MPa |
14 |
11 |
8 |
||
| Weight-increasing | 96.17%( H2SO4) =18mol/L*48h |
≤30% |
≤30% |
≤30% |
|
| 36.97%(HCL)=12mol/L*48h |
≤25% |
≤25% |
≤25% |
||
| 10% (HNO3)= 1.67mol/L*48h |
≤20% |
≤20% |
≤20% |
||
| Max. Pressure Mpa |
4.0 |
3.0 |
2.0 |
||
| Max. Temperature ℃ |
400 |
300 |
200 |
||
| Strain-decreasing %≤ |
50 |
||||
| Aging Coefficient |
0.9 |
||||
| Softness |
No Crack |
||||
| Density g/cm 2 |
1.8-2.0 |
||||
| Burning Loss % |
30 |
||||
| Compressibility |
12±5 |
||||
| Elasticity≥% |
40 |
||||
Available colour: Green, blue, white etc.
Available with tin steel, SS304 etc. wire mesh insertion
Also available with anti-stick or graphite coating
With your logo on request
DIMENSION:
1500×4000mm, 1500×2000mm
1500×1350mm, 1500×1000mm
1270×3810mm, 1270×1270mm
Thickness: 0.4~6mm
